Bridge diodes
▼D35XB80 / D40XB100
Bridge diodes which achieve a maximum rated current of 40A .Capable of large current and high power
▼LK25XB60
Improved lightning surge resistance and low VF characteristics which contribute to lower power consumption
▼US30KBV80FR
175°C guarantee,Compatible with space saving applications,large current bridge diodes
Bridge diodes which achieve a maximum rated current of 40A
Capable of large current and high power
D35XB80 / D40XB100
■800V withstand voltage / large current single phase bridge diodes
■Capable of outputting large current with standard 5S packages
(D35XB80：35A、D40XB100：40A)
■Internal structure with excellent heat dissipation
■Insulated SIP type single phase bridge diodes
(Intellectual Property Right registered structure)
■Lead temperatures of 100°C and lower
(with 25°C water cooled heat dissipation fins attached at 35 A output)
■Capable of outputting large current with standard 5S packages
(D35XB80：35A、D40XB100：40A)
■Internal structure with excellent heat dissipation
■Insulated SIP type single phase bridge diodes
(Intellectual Property Right registered structure)
■Lead temperatures of 100°C and lower
(with 25°C water cooled heat dissipation fins attached at 35 A output)
Internal structure with excellent heat dissipation
Shindengen's 5S package has an internal structure with excellent heat dissipation due to its thermal design, and the temperature difference between the four chips and terminals is extremely small. This package is ideal for bridge diodes with extremely high component reliability and mounting reliability.
The 5S package is an insulated SIP type bridge diode package, which our company was the first to release commercially worldwide, and it has become an industry standard package.
Product Specifications
| Part Name | Absolute Maximum Ratings | Electrical Characteristics | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Tstg [°C] | Tj [°C] | IF typ [A] | VRRM [V] | IFSM [A] | VF max [V] | IR max [uA] | trr max [ns] | Rth(j-c) [°C/W] | D40XB100 NEW |
-55～150 | -55～150 | 40 (Tc=85°C) |
1000 | 550 (50Hz) |
1.05 (IF=20A per diode) |
10 (VR=1000V per diode) |
27 | 0.8 |
| D35XB80 | -55～150 | -55～150 | 35 (Tc=93°C) |
800 | 550(50Hz) | 1.05 (IF=17.5A per diode) |
10 (VR=800V per diode) |
27 | 0.8 |
| D25XB80 | -40～150 | -40～150 | 35 (Tc=98°C) |
800 | 350(50Hz) | 1.05 (IF=12.5A per diode) |
10 (VR=800V per diode) |
※1 | 1.0 |
※1 Contact us for details.
Improved lightning surge resistance and low VF characteristics
which contribute to lower power consumption
LK25XB60
■600V withstand voltage / low VF bridge diodes
■Industry’s highest standard low VF of max 0.90V (LL Series)
■Lowest VF after the LL Series at max 0.95V (LK Series)
■SIP type single phase bridge diodes
■Achieves low VF in actual operation ranges
■UL1557 certified product
■Industry’s highest standard low VF of max 0.90V (LL Series)
■Lowest VF after the LL Series at max 0.95V (LK Series)
■SIP type single phase bridge diodes
■Achieves low VF in actual operation ranges
■UL1557 certified product
Internal structure with excellent heat dissipation
The 5S package is an insulated SIP type bridge diode package, which our company was the first to release commercially worldwide, and it has become an industry standard package.
Shindengen's 5S package has an internal structure with excellent heat dissipation due to its thermal design, and the temperature difference between the four chips and terminals is extremely small. This package is ideal for bridge diodes with extremely high component reliability and mounting reliability.
Industry’s highest standard low VF
Comparison table of VF characteristics with Shindengen conventional products(D25XB80).
Product Specifications
| Part Name | Absolute Maximum Ratings | Electrical Characteristics | Molding compound | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Tstg [°C] | Tj [°C] | IF typ. [A] | VRRM [V] | IFSM [A] | VF [V] | IR max [uA]※2 | Rth(j-c) [°C/W] | ||
| LL15XB60 | -55～150 | -55～150 | 15 (Tc=124°C) |
600 | 200 | typ 0.86 max 0.90 |
10 | 1.0 | Non - Green |
| LL25XB60 | -55～150 | -55～150 | 25 (Tc=113°C) |
600 | 300 | typ 0.87 max 0.92 |
10 | 0.8 | Non - Green |
| LL25XB60F | -55～150 | -55～150 | 25 (Tc=113°C) |
600 | 300 | typ 0.87 max 0.92 |
10 | 0.8 | Green (Halogen Free) |
| LK25XB60 | -55～150 | -55～150 | 25 (Tc=93°C) |
600 | 400 | max 0.95 | 10 | 0.8 | Non - Green |
※2 VR=600V per diode
175°C guarantee,Compatible with space saving applications
large current bridge diodes
US30KBV80FR
■Contribute to reduction of power consumption thanks to its high temperature operation guarantee (175°C)
■Environmentally friendly (halogen-free resin)
■Dielectric strength 2.0kV UL1557 certified product
■Environmentally friendly (halogen-free resin)
■Dielectric strength 2.0kV UL1557 certified product
contribute to reduction of power consumption thanks to its high temperature operation guarantee (175°C)
Bridge diodes which can contribute to reduction of power consumption through active utilization of diode in high temperature low VF ranges thanks to its high temperature operation guarantee.
Product Specifications
| Part Name | Absolute Maximum Ratings | Electrical Characteristics | Molding compound |
||||||
|---|---|---|---|---|---|---|---|---|---|
| Tstg [°C] | Tj [°C] | IF typ. [A] | VRRM [V] | IFSM [A] | VF max [V] | IR max ※3 | Rth(j-c) [°C/W] | ||
| US30KBV80FR | -55～175 | -55～175 | 30 (Tc=126°C) |
800 | 350 | 1.05 | 5 | 0.8 | Green (Halogen Free) |
| US30KB80R | -55～150 | -55～150 | 30 (Tc=97°C) |
800 | 350 | 1.10 | 10 | 0.8 | Non - Green |
※3 VR=600V per diode
