ST02-520F2・ST10-520F2
High Voltage 500V Class TVS Diode
- Now developing new TVS part with 500V range
- Capable for continuous avalanche
Suitable for automotive inverters
|
Part Name |
Absolute Maximum Ratings |
Electrical Characteristics |
|||||
|
PRSM[W] |
Tstg[°C] |
Tj[°C] |
VR(DC)[V] |
VBR [V] |
IR max[uA] |
||
|
min |
max |
||||||
|
ST02-520F2 |
200 *1 |
-55～150 |
-55～150 |
440 |
490 |
550 |
5 *2 |
|
ST10-520F2 |
1000 *1 |
-55～150 |
-55～150 |
440 |
490 |
550 |
5 *2 |
*1 : Planned *2 : VR = VR (DC)
Samples are available!
